ViewLab3D is the software that allows to integrate into a single enhanced 3D graphic environment data and models from ERT measurements with images, three-dimensional graphical objects and DXF files. These features allow to add to the view of ERT models inverted with ERTLab™ elements such as buildings, trees, roads, waterways, walls or other objects that allow a clearer orientation of the represented resistivity volumes.

Download area

 Download ViewLab3D

The following Microsoft update can be necessary:
Microsoft Visual C++ 2005 Service Pack 1 Redistributable Package MFC Security Update
Select "vcredist_x86.EXE".
A final reboot can be necessary.

Download ViewLab3D and evaluate it in DEMO mode that allows you to try all the features of the software for a period of 5 days (we have to enable your trial license via the web and you need the ERTLab USB key inserted to run the software).

For the FULL version you need a license, please contact us for further information.

Technical specifications

Supported OS

Windows XP, 7, 8, 10.


  • User-defined view of the electrode object (color, size, labels and cable drawings).
  • Topography display by points or interpolated surface with variable smoothing effect.
  • Mesh view.
  • Automatic export of multiple sections by user-defined steps.
  • Easy contouring management: user-defined number, size, colors of contours.
  • Lots of available colormaps according to main mapping software standards.
  • Object insertion from DXF files.
  • Inclusion of 3D graphics objects.
  • Export in BMP, PNG, JPG, TIFF, VRML.
  • Load/save script files with session settings.
  • Manage multiple projects in a single session.
  • Simultaneous display of sections, volumes or isosurfaces of resistivity, chargeability and sensitivity, each with its own colormap.


ERTLab Studio gallery

General 3D view with picture
General 3D view with picture
General 3D view with picture
Marine ERT acquisition
Geotechnical investigation
Large scale survey
Large scale ERT survey
Structural model on shallow survey
IP large scale survey
Geotechnical investigation
Geotechnical investigation - Field Data
ERT Survey
3D survey and topography
ERT Survey for geotechnical purpose
ERT prospection and aerial photo
ERT Prospection with house
